Iridium Repeater Kits

Iridium indoor repeater schematic

  • Complete solution for using Iridium devices (e.g. satphones) indoors without sky-view
  • Use satellite comms without leaving secure surroundings
  • Typically used in:
    • Large buildings
    • Underground facilities
    • Military bunkers
    • Aircraft hangars *
    • Disaster/emergency communications
    • Ships/oil rigs
  • Optical fibre extends the distance from outdoor antenna to indoor location by up to 3km
  • Supports up to 3 satphones simultaneously
  • Originally designed for military use – truly plug-and-play
  • Simple installation – kits come with all you need
  • Supports L1 GPS
Repeater KitsTechnical specificationsAbout IridumInstallation video

Iridium repeater kits come with all the parts needed for a successful installation apart from the optical fibre.

Option 1 – extends distance from antenna to indoors by <3Km

Iridium indoor repeater schematic
The outdoor unit (ODU) and indoor unit (IDU) can be connected to existing optical patch panels or new optical fibres can be installed especially for the job.

Optical fibre is available from some suppliers with pre-installed connectors – FalTech can advise and source fibre for you, or put you in touch with an experienced optical fibre vendor.

Each kit contains:

  • Two Iridium outdoor antennas
  • IP65-rated optical outdoor unit (ODU)
  • Rack-mounted 19″ 1u optical indoor unit (IDU)
  • Two ceiling-mounted indoor antennas

More indoor antennas can be added by installing signal splitters and coaxial cables.



Option 2 – coaxial cable only – ideal for aircraft hangars

Iridium_indoor_repeater_coaxialFor situations where physical separation of >3Km is not required.

Outdoor unit (ODU) and indoor unit (IDU) now combined into one enclosure with no optical fibre interfaces.

Each kit contains:

  • Two Iridium outdoor antennas
  • IP65-rated combined ODU/IDU
  • Two ceiling-mounted indoor antennas

Up to 5,000 ft2 of hangar space can be covered by a single system with a ceiling height of 130 ft.

Iridium Optical repeater specifications

Downlink

  • Frequency range: 1500 – 1650MHz
  • ODU Input/IDU output VSWR:   1:1.6
  • ODU RF input signal range [total power]: up to -20dBm
  • Downlink Gain: >50dB
  • Noise Figure: <5dB
  • Indoor coverage: >400sqm

Uplink

  • Frequency range: 1500 – 1650MHz
  • IDU Input/ODU Output VSWR:   1:1.6
  • IDU RF Input signal range [total power]: up to 0dBm
  • Uplink Gain: >50dB
  • Noise Figure: <5dB
  • Indoor Coverage: >200sqm

Optical Specifications

  • Required fibre type: Dual SMF-28 or equivalent [single mode]
  • Optical wavelength: 1310 ±10nm
  • IDU/ODU optical power output: -3dBm / 0.5mW (Min)
  • Optical connector: SC/APC or FC/APC
  • Fibre length: 3Km max (2dB).

Physical Specifications

  • RF connectors (IDU): Single SMA Female
  • RF connectors (ODU): Dual N-Tpe Female
  • Dimensions (IDU): 19” Wide 1U Chassis
  • Dimensions (ODU): 14″ × 6″ × 3″
  • Operating temperature (IDU):-20 to +55° C
  • Operting temperatures (ODU): -30 to +55° C
Iridium Communications Inc. is a Virginia, USA-based company that provides a truly global voice and data communications service via the world’s largest commercial satellite constellation.

The Iridium network provides high-quality voice and data connections over the entire surface of the planet – across continents, oceans, airways and even the polar regions.

The constellation consists of 66 cross-linked, low-Earth orbit (LEO) satellites (plus six in-orbit spares), operating as a fully-meshed network.

This comprehensive coverage footprint provides a highly dependable, critical communication lifeline to a wide variety of users the world over.

Iridium Coverage
The graphic illustrates how the 66 satellites achieve global coverage, at a height of approximately 483 miles above the Earth’s surface.

There are 11 satellites in each of 6 orbital planes, with orbits roughly “crisscrossing” above the north and south poles.



Iridium network: facts and figures:

  • Satellites are travelling at 17,000 miles per hour, completing an orbit of the Earth in about 100 minutes.
  • The time taken to cross the sky from horizon to horizon is approximately 10 minutes.
  • Each fast-moving satellite communicates with adjacent satellites in front, behind and alongside its own orbit.
  • Each satellite can project 48 spot beams on to the Earth’s surface; the size of each spot beam is approximately 250 miles in diameter.
  • The satellite’s 48-beam footprint is around 2,800 miles in diameter.
  • All spot beams and satellite footprints overlap, which is ultimately what provides the seamless global coverage.
Iridium repeaters enable transmission of Iridium and GPS signals from outdoor to indoor.

This video explains the installation process for Iridium and GPS optical repeaters and the basic functionality of the system.
